Bobcat 130 Hydraulic Excavator Repair Manual
Price range: $14.00 through $28.00
| 🚜 Equipment | |||
|---|---|---|---|
| Brand | Bobcat | ||
| Type | Hydraulic Excavator | ||
| Model | 130 | ||
| 📄 Documents | |||
| Language | English | ||
| Format | |||
| Title | Publication No. | Pages | |
| Repair Manual | 6570485 | 222 | |
| Operation & Maintenance | 6570364 | 94 | |
- Description
- Additional information
- Table of Content
- Specification
- Buyer Questions & Answers
- Reviews (0)
Introduction
This shop manual is designed to give you a clear, hands-on guide to every major component group, breaking each chapter into four easy-to-follow sections:
Structure and Function – how each part is built and works, laying the groundwork for effective troubleshooting
Testing and Adjusting – the checks and calibrations to perform before and after repairs
Disassembly and Assembly – step-by-step removal and reinstallation procedures, with all key precautions
Maintenance Standard – the criteria you use to inspect parts and decide whether they meet service limits
Use these four sections as your roadmap in the workshop—start with “Structure and Function” to understand the component, move on to “Testing and Adjusting” to verify performance, follow “Disassembly and Assembly” for the actual repair work, and finish with “Maintenance Standard” to confirm everything is within spec.
| Manual | Repair Manual, Operation & Maintenance Manual |
|---|
Table of Content
📙 Table of Contents
ENGINE
- Structure and Function
- Testing and Adjusting
- Disassembly and Assembly
POWER TRAIN
- Structure and Function
- Disassembly and Assembly
- Maintenance Standard
UNDERCARRIAGE
- Structure and Function
- Disassembly and Assembly
- Maintenance Standard
HYDRAULIC SYSTEM
- Structure and Function
- Testing and Adjusting
- Disassembly and Assembly
- Maintenance Standard
WORK EQUIPMENT
- Disassembly and Assembly
ELECTRICAL SYSTEM
- Structure and Function
Specification
| Model | Years | Engine (disp / cyl) | Power (hp) | Width (in) | Max Dig Depth (in) | Operating Weight (lbs) | Hydraulic Flow (gpm) | Bucket Dig Force (lbf) |
|---|---|---|---|---|---|---|---|---|
| 130 | 2000–2002 | 2.4 L / 3-cyl | 74 | 78 | 96 | 9 261 | 24 (std) / 30 (hi-flow) | 7 000 |
