Ford CL-35, CL-45 Compact Loader Repair Manual

Ford CL-35, CL-45 Compact Loader Repair Manual

$32.00

🚜 Equipment
Brand	FORD
Type	Skid-Steer Compact Loader
Model	CL-35, CL-45
📄 Documents
Language	English
Format	PDF
Title	Publication No.	Pages
Repair Manual	40003510	306
Reference Manual	40002540	44

The Ford CL-35 and CL-45 Compact Loaders are robust skid-steer loaders designed for construction, agricultural, and industrial applications. Equipped with reliable engines producing 29 hp (CL-35) and 40 hp (CL-45), these machines deliver rated operating capacities of 1,000 lbs and 1,300 lbs respectively. Their compact size, combined with skid-steer maneuverability, makes them ideal for tight jobsite operations while still providing ample lifting power and productivity. Standard bucket widths of 54 inches ensure efficient material handling, grading, and loading performance.

Both the CL-35 and CL-45 are engineered with hydrostatic drive systems for smooth, infinitely variable speed control. The hydraulic system powers loader arms, pumps, and cylinders with dependable performance, while the main frame and rugged construction provide long-lasting durability. A simple operator platform with essential controls and gauges makes these loaders easy to operate and maintain, while their compact dimensions ensure stability and versatility across a variety of jobsite conditions.

The comprehensive repair manual covers every system of the Ford CL-35 and CL-45. Key sections include hydraulic system servicing, hydrostatic drive system, final drive, controls, electrical system, main frame, engine repair, and maintenance specifications. Step-by-step procedures, troubleshooting guides, lubrication charts, wiring diagrams, and exploded component views allow technicians and operators to accurately service, diagnose, and maintain these machines to factory standards. This ensures maximum uptime and reliability for owners and operators alike.

Key Highlights

Ford CL-35: 29 hp engine, 1,000 lbs rated operating capacity, 54-inch bucket
Ford CL-45: 40 hp engine, 1,300 lbs rated operating capacity, 54-inch bucket
Hydrostatic drive system for variable-speed operation
Durable hydraulic pumps, valves, and cylinders for loader performance
Compact skid-steer design for maneuverability and stability
12-volt electrical system with reliable starting and controls
Workshop manual sections: hydraulic, hydrostatic drive, final drive, controls, electrical, main frame, engine, and maintenance
Includes wiring diagrams, lubrication charts, torque data, and troubleshooting guides
Step-by-step disassembly, inspection, and reassembly instructions
Essential for reducing downtime, ensuring reliability, and extending machine life

Publication	40003510, 40002540
